looks at slides

I see where the anime catgirl logo that Anubis uses came from.

What makes this worse is that git servers are the most pathologically vulnerable to the onslaught of doom from modern internet scrapers because remember, they click on every link on every page.

The especially disappointing thing is that, for the specific case that Xe was running into, a better-written scraper could just recognize that this is a public git repository and just git clone the thing and get all the useful code without the overhead. Like, it’s not even “this scraper is scraping data that I don’t want it to have”, but “this scraper is too dumb to just scrape the thing efficiently and is blowing both the scraper’s resources and the server’s resources downloading innumerable redundant copies of the data”.

It’s probably just as well, since the protection is relevant for other websites, and he probably wouldn’t have done it if he hadn’t been getting his git repo hammered, but…

EDIT: Plus, I bet that the scraper was requesting a ton of files at once from the server, since he said that it was unusable. Like, you have a zillion servers to parallelize requests over. You could write a scraper that requested one file at once per server, which is common courtesy, and you’re still going to be bandwidth constrained if you’re schlorping up the whole Internet. Xe probably wouldn’t have even noticed.

https://en.wikipedia.org/wiki/National_Helium_Reserve

The National Helium Reserve, also known as the Federal Helium Reserve, was a strategic reserve of the United States, which once held over 1 billion cubic meters (about 170,000,000 kg)[a] of helium gas.

The Bureau of Land Management (BLM) transferred the reserve to the General Services Administration (GSA) as surplus property, but a 2022 auction[10] failed to finalize a sale.[11] On June 22, 2023, the GSA announced a new auction of the facilities and remaining helium.[12] The auction of the last helium assets was due to take place in November, 2023.[13] Though the last of the Cliffside reserve was to be sold by November 2023, more natural gas was discovered at the site than was previously known, and the Bureau of Land Management extended the auction to January 25, 2024 to allow for increased bids.[14] In 2024 the remaining reserve was sold to the highest bidder, Messer Group.[15]

Arguably not the best timing on that.

Sure. What that guy is using is actually not the most-interesting diagram style, IMHO, for automatic layout of network maps, if you want large-scale stuff, which is where the automatic layout gets more interesting. I have some scripts floating around somewhere that will generate very large network maps — run a bunch of traceroutes, geolocate IPs, dump the results into an sqlite database, and then generate an automatically laid-out Internet network map. I don’t want to go to the trouble of anonymizing the addresses and locations right now, but if you have a graphviz graph and want to try playing with it, I used:

goes looking

Ugh, it’s Python 2, a decade-and-a-half old, and never got ported to Python 3. Lemme gin up an example for the non-hierarchical graphviz stuff:

graph.dot:

graph foo {
    a--b
    a--d
    b--c
    d--e
    c--e
    e--f
    b--d
}

Processed with:

$ sfdp -Goverlap=prism -Gsep=+5 -Gesep=+4 -Gremincross -Gpack -Gsplines=true -Tpdf -o graph.pdf graph.dot

Generates something like this:

That’ll take a ton of graphviz edges and nicely lay them out while trying to avoid crossing edges and stuff, in a non-hierarchical map. Get more complicated maps that it can’t use direct lines on, it’ll use splines to curve lines around nodes. You can create massive network maps like this. Note that I was last looking at graphviz’s automated layout stuff about 15 years ago, so it’s possible that they have better layout algorithms now, but this can deal with enormous numbers of nodes and will do reasonable things with them.

I just grabbed his example because it was the first graphviz network map example that came up on a Web search.

It will be interesting to see how well that goes over with the isolationist Trump supporters who liked the idea of non-involvement abroad and thought that that was what they were getting with Trump.

It sounds like Tucker Carlson, for example, which has been playing to the isolationist crowd, has been pretty critical of activity in Iran.

So that when setting up a new system, you can migrate all your user configuration easily, while also version-controlling it.

The old lighting wasn’t that great anyway. If I were to just put lighting on a DMX512-controlled network, then all of it could be synchronized to whole-house audio…

It seems like a good time to learn graphviz’s dot format for the network layout diagrams, with automated layout.

https://mamchenkov.net/wordpress/2015/08/20/graphviz-dot-erds-network-diagrams/

Probably a good idea to switch over to WPA-Enterprise using Authentik’s RADIUS server support and let all of the users of your wireless access point log in with their own network credentials, while you’re at it.

You have all your devices attached to a console server with a serial port console set up on the serial port, and if they support accessing the BIOS via a serial console, that enabled so that you can access that remotely, right? Either a dedicated hardware console server, or some server on your network with a multiport serial card or a USB to multiport serial adapter or something like that, right? So that if networking fails on one of those other devices, you can fire up minicom or similar on the serial console server and get into the device and fix whatever’s broken?

Oh, you don’t. Well, that’s probably okay. I mean, you probably won’t lose networking on those devices.

You have remote power management set up for the systems in your homelab, right? A server set up that you can reach to power-cycle other servers, so that if they wedge in some unusable state and you can’t be physically there, you can still reboot them? A managed/smart PDU or something like that? Something like one of these guys?

Oh. You don’t. Well, that’s probably okay. I mean, nothing will probably go wrong and render a device in need of being forcibly rebooted when you’re physically away from home.

You have squid or some other forward http proxy set up to share a cache among all the devices on your network set up to access the Web, to minimize duplicate traffic?

And you have a shared caching DNS server set up locally, something like BIND?

Oh. You don’t. Well, that’s probably okay. I mean, it probably doesn’t matter that your devices are pulling duplicate copies of data down. Not everyone can have a network that minimizes latency and avoids inefficiency across devices.

All of those systems in your homelab…they aren’t all pulling down their updates multiple times over your network link, right? You’re making use of a network-wide cache? For Debian-family systems, something like Apt-Cacher NG?

Oh. You’re not. Well, that’s probably okay. I mean, not everyone can have their environment optimized to minimize network traffic.

You have an intrusion detection system set up, right? A server watching your network’s traffic, looking for signs that systems on your network have been compromised, and to warn you? Snort or something like that?

Oh. You don’t. Well, that’s probably okay. I mean, probably nothing on your network has been compromised. And probably nothing in the future will be.

All of your systems are set up, but are they capable of being redeployed using a configuration management software package? Ansible or something like that?

Oh. They’re not. Well, that’s probably okay. I mean, you could probably go manually reproduce configurations, more or less.

logging is probably down

You do, of course have a dedicated rsyslogd server? An isolated system to which logs are sent, so that if someone compromises another one of your systems, they can’t wipe traces of that compromise from those systems?

Oh. You don’t. Well, that’s okay. Not every lab can be complete. That Raspberry Pi over there in the corner isn’t actually doing anything, but it’s probably happy where it is. You know, being off, not doing anything.

Relevant:

https://en.wikipedia.org/wiki/Forge_(software)

That was the enrichment facility, but Iran won’t have kept the output it generated prior to it being bombed there.

If you can use Termux, you can use the command-line lftp, which supports SFTP; I use this on Linux, so I’m familiar with it.

$ pkg install lftp
$ lftp sftp://foo.com

I also use rsync in Termux after being exasperated over the lack of a reasonable F-Droid graphical client for that.

I wound up using some non-open-source graphical SCP or SFTP client out of the Google Play Store using Aurora Store’s anonymous login at one point, which worked but wasn’t what I wanted to use.

https://en.wikipedia.org/wiki/Khamenei_family

Assuming that Mojtaba Khamenei meets with an untimely demise in the near future, apparently there are two other sons after this: Mostafa Khamenei and Masoud Khamenei.
